CHASSIS
• Ford F550 XL 4x4 60CA Diesel extended cab
• Nerf style cab running boards
• 9,000 lb. Front hitch with winch power
• 16,000 lb. Class V Rear hitch with winch power & trailer plug for mounting Warn portable winch Zenon 10s 10,000 lb.
• Fab Fours HD Steel bumper
• 40” Super Single wheels with a 4” lift kit

BODY
• 96.5” W x 120” L Magnum Aluminum Platform
o Extruded Aluminum Box Tube Floor
o 14” Smooth Aluminum Mill Finish Rear Apron w/ LED ST/TL & BU’S
o LED Body Lights, mud flaps, backup alarm
• Rear body rubber D-bumper
• Aluminum diamond plate body side skirt
• Anodized aluminum C-Channel rubrails
• Custom fabricated aluminum side compartments with ROM roll up doors
• Custom fabricated aluminum transverse compartments with ROM roll up doors
• Diamond plate underbody compartments
• Roll out toolboards (2) in transverse compartment
• 2 x Aluminum hose trays
• Folding steps & grab rail at rear
• Lettering & reflective stripe
• 3M diamond grade rear body & skirt reflective chevron

PUMP & TANK
• 300 Gal UPF Defender 1 custom water tank with sump and 10Gal foam cell
• 2 x Hannay aluminum polished reels with electric rewind for up to 200’ of 1” or 300’ of ¾” booster hose
• CET SM-PFP-25HPDSL-MR Skid mounted pump
o 230 GPM @ 100 PSI, 145 GPM @ 150 PSI, 105 GPM @ 175 PSI
o Diesel 25Hp Kubota engine connected to truck fuel tank
o Stainless steel intake & discharge manifold
o 1" Akron tank fill
o 2 x 1.5NHF 1 1/2" Akron ball valve discharges with cap and chain
o 2 x 1” Akron hose reel valves
o Pressurize air fitting to blow out line
o Suction FT (2) Standard suction with two 2 1/2" Akron ball valve & 2.5 NHF INLET
• Scotty round the pump foam system
• Class 1 electronic water tank level gauge ITL

ELECTRICAL
• Tecniq LED compartment strip lights (2 per compartment)
• Whelen Core programmable vehicle control system
• Whelen 10 light inner edge lightbar inc 2 x white take down lights
• Whelen Duo Ion-T and Strip-lite warning lights
• 4 x Tecniq P-06 2000lm LED Work lights switched at pump controls
• Tecniq D07 LED perimeter lights
• Whelen 100W Siren
• Kussmaul auto eject & charger
